Cambo WRC-491 WRC Compact with integrated Hasselblad CFV Interface

The Cambo WRC-490/491 come with either an integrated Phase One/Mamiya or Hasselblad CFV interface.

Here is the perfect portable solution for high-quality medium format digital imaging. The Wide Compact is ideal for photographers who want to travel as light as possible, but still be able to produce the highest quality images.

The Cambo WRC-490 and WRC-491 are the technical cameras of choice for those who value a compact form factor combined with optimum usability. This camera offers 20/20mm of Shift or Rise/Fall. Depending on the orientation of the body, which is changed by a 90° flip around the tripod mount. To make these movements available in portrait and landscape orientation, we’ve integrated a rotatable interface plate for the digital back as well.

The WRC-490/491 share the lens mount with the other Cambo WDS/WRS and Phase One XT tech cams. Newly designed rear spacers enable the use of short barrel lens panels. Many lens panels can be fitted with an optional Tilt/Swing mechanism.

New Rodenstock Digaron lenses are available in Aperture Mount or X-Shutter. Cambo offers a retroffiting service for many legacy Schneider and Rodenstock lenses. This gives access to an extensive range of focal lengths, reaching from 19 to 180mm and beyond on request.

Cambo WRC-490 comes with an integrated Phase One/Mamiya interface
Cambo WRC-491 comes with an integrated Hasselblad CFV interface

Technical Details
Small size  156 x 134mm (W x H) excl. handgrips and tripod mount, and Interface
Lightweight only 0.97 kgs (excl. lens)
Horizontal shift 40 mm (20 mm left/20 mm right)
or Vertical shift 40 mm (20 mm left/20 mm right)
Removable 3/8" tripod mount (25 mm)
including Arca-compatible base plate.

Key Features:
Compatible with Cambo’s WRS system
Integrated Portrait/Landscape rotation of the back
Integrated Portrait/Landscape rotation of the camera body
Lightweight - only 0.97 kg (excl. lens)
Millimetre scales for movements
Integrated Arca-compatible tripod mount
1/4 - 3/8" mount
2 Integrated spirit levels
2-point fixation accessory mount

Exterior
High-grade aluminium body in black anodised finish
Single handgrip
Stainless steel drive knob for shifts or rise/fall

Accessories and options
Optional WTS Tilt-Swing Lens Panels
Broad range of optics, including Phase One X-Shutter lenses
Retrofitting of legacy lenses offered

Interfaces and Lenspanels

Interfaces
The Cambo WRC-490/491 come with either an integrated Phase One/Mamiya or Hasselblad CFV interface. For the adaptation of legacy digital backs, we'd like to refer to our other WRC and WRS models.

Lenspanels
In order to accomplish nearly any architectural or landscape assignment, we offer a broad range of Rodenstock HR Digaron lenses. Choose from focal lengths ranging from 23mm up to 180mm. Legacy lenses - like Schneider Kreuznach - can be retrofitted on request.

Register for an extended warranty
Register on Cambo's website now to receive your extended 2-year warranty.

Lens and back not included
